DESCRIPTION

Basic Info.

Model NO.	cat5e
Cover Material	PVC
Type	Cat 5
Material Shape	Round Wire
Conductor Type	Solid
Wire Core Material	Bare Copper Wire
Certification	CE, ISO, RoHS, CCC, VDE
Model	Cat5e
Brand	Cx-Cable
Size of Conductor	25/24/23 AWG
Numbers of Conductor	8
Insulation	HDPE
Color	Customized
Jacket	PVC/PE/LSZH
Test	Fluke
Use for	Network/Alarm System
Transport Package	Customized
Specification	customized
Trademark	OEM or CX-Cable
Origin	Hangzhou Zhejiang
HS Code	8544491100
Production Capacity	50000boxes/Per Month

Product Description

Material Instruction:
1.CCA or 24AWG Soft Plain Copper.
2.Eco-friendly,pollution-free and new materials selected.Promise new material only.
3.Insulation: Solid HDPE;
4.Eco-friendly PVC/LSZH Jacket , high-temperature resistance,long working life.

Linan Chuangxiang Cable Co., Ltd is a professional cable manufacturer in China,we have more than 11years in this line.

Our productions comply with ISO9001.Professional team,powerful factory and strict quality control give best service to our clients
and the quality guarantee in every order.

Our products have been widely installed in Telecom companies and many distributors around the world,and we sincerely look for-
ward to woking with all clients from all over the world.

Main products:
1,Optical Fiber Cable and Patch Cord
2.Lan and Network Cable and Patch Cord
3.Alarm Cable and Speaker Cable
4.Drop Wire and Telephone Cable
5.Communication Cable
6.Coaxial Cable
7.Electrical Wire and Power Cable
8.Telecom Accessory.

1.Are you the real manufacturer?
Yes. We are the real manufacturer,which is specialized in coaxial cable,lan cable and optical cable,etc.

2.Can you accept small order?
Yes,We support new project of our customers,and we know business is always from small order.

3.What is your delivery time?
Usually within 30days after we received deposit.

4.What is your payment way?
T/T, L/C,it can be negotiated.

5.Can you supply customized products and logo?
Yes. We supply OEM&ODM service.

If you were interested in our competitive products,pls call me,let's talk more!

Type	FTP CAT5e
Conductor	24/25AWG CU/CCA
Insulation	1.03+/-0.2mm HDPE
Total number of insulated conductor	8, twisted in 4 pairs
Color code	white-blue/blue,white-orange/orange, white-green/green,white-brown/brown
Overall Shield	Al Foil+PET
Drain wire	0.5mm BC/TC/CCA
Outer Jacket	5.8+/-0.2mmPVC/PE/LSZH

Impedance 1.0-100.0MHz (ohms)	100±15
D.C, Resistance @20ºC(ohms/km)	≤9.5
D.C. Resistance Unbalance(%)	Max 2.5
Insulation Resistance	>5000MΩ*KM
Rated Temperature	70ºC

Frequency (MHz)	Return loss (dB)	Attenuation (dB/100m)	NEXT (dB)	FEXT (dB)
1	20.00	2.10	64	63.8
4	23.01	4.30	55	51.7
10	25.00	6.60	49	43.8
16	25.00	8.20	46	39.7
20	25.00	9.20	44	37.7
31.25	23.64	11.80	42	33.8
62	21.54	17.10	37	27.6
100	20.11	22.00	34	23.6
